T-MOTOR FLAME 80A HV 6-12S Brushless ESC

T-MOTOR flame 80A HV esc support 6-12s lipo battery. With the layered structure, it is more efficient and has better heat dissipation.It is perfectly compatible with U10 Plus,U11 and U12 series motors.

Main Features:
1. Special core program for multirotor controllers greatly improves throttle response.
2. Specially optimized software for excellent compatibility with disc-type motors.
3. All settings except the timing are preset, making usage simple, highly intelligent and adaptive.
4. Compatible with various flight-control systems and supports a signal frequency of up to 600Hz.
5. CNC aluminium alloy enclosure, IP55 PCB with nao technology, widely used in special domain such as UAV for agriculture, searching and etc.
6. Supporting 6-12S lipo

Specifications:
Item Brand: T-Motor
Item Model: Flame 80A
Size: 62 x 41 x 17mm
Weight: 106g
Support Voltage: 6-12S
BEC: No
Con. Current: 80A
Peak Current: 120A
Programable Items: Timing (High/Intermediate)

Package Included:
T-MOTOR Flame 80A HV Brushless ESC x 1
User Manual x 1
