ToolkitRC M7 200W 10A 2-6S DC Multifunctional Balance Charger

ToolkitRC M7 200W 10A DC Balance Charger Discharger for 1-6S Lipo Battery with With Voltage Servo Checker ESC Tester Receiver Signal Tester Quick Charger Function

Features:
1.More power than before,same size as the M6 with 33.3% more power;
2.Maximum output 200W and 10A;
3.IPS 2.0” wide angle display 320*240 resolution;
4.Scroll wheel for better control;

Specifications
LCD: IPS 2.0inch LCD 320*240 Pixel
Product size: 73*51*27 mm
Pack size: 84*79*39 mm
Product weight: 90g
Pack weight: 150g
Discharge power: 200W @MAX 10A Recycle mode / 10W@3A Normal mode
Type of battery: Lipo LiHV LiFe Lion@1-6S / NiMh @1-16S Pb @1-10S
Input voltage 7.0-28.0V @MAX 12A
Charger power: 200W @MAX 10A
Balance current400mA @2-6S
USB: 2.1A @5.0V or Upgrade

INPUT:
PWM: 880-2200us @20-400Hz
PPM: 880-2200us*8CH @20-50Hz
SBUS: 880-2200us*16CH @20-100Hz
Voltage: 1.0-5.0V @1-6S
Internal resistance: 1-99mR @1-6S
ESC: 200W@10A | PWM Output

OUTPUT:
PWM: 500-2500us @20-1000Hz
PPM: 880-2200us*8CH @20-50Hz
SBUS: 880-2200us*16CH @20-100Hz
Power supply: 1.0-28.0V @1.0-10A mode:CC+CV
OverCurrent Cutoff time: <5ms

Package Includes:
1x ToolkitRC M7 Charger
